The TM5500 is a heavy-duty railcar mover designed for industrial and rail yard operations. It features a robust frame, powerful engine options, and a specialized weight transfer system that enhances traction and stability.
The TM5500 is engineered to operate efficiently on both rail and road surfaces, making it a versatile choice for moving railcars within facilities.
This model is known for its durability, ease of maintenance, and efficient performance in demanding environments. It is equipped with hydraulic and mechanical systems that ensure safe and reliable.
Key Specifications:
| Specification | Details |
|---|---|
| Engine | 6-cylinder industrial engine (Gasoline or optional Diesel), 116 BHP at 2400 RPM |
| Fuel Capacity | 17 gallons (approx. 8 hours of operation) |
| Torque Converter | 3.5 to 1 torque multiplication ratio |
| Transmission | 3 speeds forward (Low: 12.96:1, Intermediate: 4.70:1, High: 1.62:1); 3 speeds reverse |
| Brakes | Hydraulic service brakes, mechanical parking brake, rail-mounted brake |
| Rail Wheels | 18" diameter, heat-treated cast steel |
| Road Wheels | Heavy-duty retractable suspension with 8-ply tires |
| Steering | Mechanical truck-type linkage |
| Coupler | Heavy-duty, cast steel, Trackmobile-pioneered weight transfer design |
| Maximum Speed | On Rail: Low - 5.3 MPH, Intermediate - 14 MPH, High - 30 MPH; On Road: Low - 3.75 MPH, Intermediate - 10.3 MPH, High - 25 MPH |
| Maximum Tractive Effort | On Rail: 17,500 lbs; On Road: 3,600 lbs |
| Weight | 14,000 lbs |
| Dimensions | Overall Length: 144", Width: 96", Height: 108" |
Top Features
-
Dual Mode Operation – Can function on both roads and rails for maximum flexibility.
-
High Traction Performance – Uses weight transfer technology to increase rail traction.
-
Powerful Engine Options – Available with gasoline or diesel engine configurations.
-
Heavy-Duty Construction – Built with a welded steel frame for durability.
-
Advanced Braking System – Includes hydraulic service brakes and a mechanical parking brake.
-
Comfortable Cab – Enclosed driver cab with 360° visibility, ergonomic controls, and optional heating.
-
Optimized for Industrial Use – Designed for efficient movement of railcars in industrial environments.
Delivery and Pickup Instructions
We understand that time is critical for your projects. That’s why we offer same-day delivery and pick-up to your location, ensuring you get the equipment you need, exactly when you need it.
Delivery Process
- Orders placed before [12:00 PM] qualify for same or next-day delivery.
- Road restrictions on heavy equipment transport may affect delivery times and routes. If any delays occur, our team will notify you as soon as possible.
- Our team will coordinate with you to confirm the best delivery time and location.
- All equipment will arrive fully inspected, fueled (if applicable), and ready for immediate use.
Pick-Up Process
- Same-day pick-up is available upon request.
- Please ensure the equipment is cleaned and refueled before pick-up.
- Our driver will conduct a quick inspection to verify the condition of the equipment.
Why Rent From On-Track Rentals
We know our equipment inside and out. Our team of experienced mechanics ensures every machine is regularly serviced and maintained to perform at its best.
When you rent from us, you're not just getting equipment - you’re getting reliability, efficiency, and peace of mind.
